12V-300Ah(HS02-1230)Lithium Iron Phosphate Battery
12V-300Ah(HS02-1230)Lithium Iron Phosphate Battery
Product Description
| Nominal Voltage (customizable) | 12.8V | |
| Rated Capacity (customizable) | 300Ah | |
| Combination Mode | 4S2P | Professional energy storage cell |
| Ceiling Voltage | 14.6V ± 1V | Charging cut-off voltage/maximum charging voltage |
| Minimum Voltage | 10V ± 1.0V | Discharge cut-off voltage |
| Continuous Operating Current | ≤100A | Maximum normal operating current |
| Maximum Transient Current | ≤200A | Overcurrent protection value |
| Overcharge Protection Voltage | 3.65V ± 0.025V/Cell | / |
| Over Discharge Protection Voltage | 2.50V ± 0.025V/Cell | / |
| Charging Mode | Constant current and constant voltage (CC-CV) | / |
| Charging Current | ≤100A | / |
| Charging Temperature Range | 0~45℃/45~85%RH | / |
| Discharge Temperature Range | -20~55℃/45~85%RH | / |
| Shell (customizable) | Plastic shell | / |
| Plug (customizable) | M8 screw hole | |
| Overall Dimension (customizable) |
L(523mm)*W(240mm)*H(215mm) |
Size reference sample |
| Weight | ≤26kg | / |
| Signal Communication | Bluetooth | Customizable |
| Heating | Turn on at 0 ℃ and turn off when heated to 10 ℃ | Customizable |
| Certified | CE, UN38. 3. MSDS, shipping, hazardous package | |
| Cell Certification | CE,UL,IEC 62109-1&-2, IEC 62477,EN61000,UN38.3 | |
